UL DLC Nano LED tube

                                        Installation：

                                        a,work with electronic ballast ,no need rewiring

                                        b,If ballast broken, can rewiring AC100-277V connect directly

                                              Method A： Work with magnetic ballast

                                              Connect with Magnetic ballast:

                                                 1.Turn off the power

                                                 2.Remove the  fluorescent tube

                                                 3.Install ARK led tube in one end

                                                 4.Turn on the light

                                        If ballast broken, can rewiring AC96-265V connect directly

                                        Method B：AC100-277V Connect Directly:

                                                1.Turn off the power

                                                2.Take out the ballast and starter,rewiring

                                                3.AC 100-277V connect directly

                                                4.Turn on the light.
