Magnetic LED strip lights retrofit kits (T5 size)

Magnetic LED strip lights retrofit kits (T5 size)

Arkshine magnetic led troffer retrofit kit is a long lasting and money-saving solution that retrofit traditional 1x4, 2x2, 2x4 light fixtures.Kits offer high efficiency 140-150lm/w, Eco-Friendly,and simple magnetic installation.Applications including offices,lobbies, hallways and conference rooms in schools municipalities,libraries, airport, healthcare facilities and so on .


Magnetic LED strip lights retrofit kits (T5 size)Magnetic LED strip lights retrofit kits (T5 size)
Inquire Now


FEATURES:

- Input at AC100-277V  or AC 347

- 3000-6500K CCT

- 150lm/w without cover or 140lm/w with cover

- External driver from 9w to 72w

- Non-dimming or 0-10v dimming as option.

- permanent-magnet and installation hole on both end

- Small size, saving shipping cost.

- Quick connect in 3 mins with magnetic.

- Five years warranty

- Replace kind of sizes fixtures.1x2', 2x2', 3x2', 4x2', 1x4', 2x4', 3x4', 4x4'.

magnetic led troffer retrofit kit specification

Configuration:


Model

Size

Power

Luminous

Dimmable

CRICRI

ARK/DT/8YXXD106(15D)

2FT

8W

1200LM±10%

0-10v Dimming

80+3000K
4000K
5000K
6000K

ARK/DT/16YXXD206(15D)

2FT

16W

2400LM±10%

0-10v Dimming

ARK/DT/24YXXD306(15D)

2FT

24W

3600LM±10%

0-10v Dimming

ARK/DT/32YXXD406(15D)

2FT

32W

4800LM±10%

0-10v Dimming

ARK/DT/8YXXD106(15N)

2FT

8W

1200LM±10%

NON

ARK/DT/16YXXD206(15N)

2FT

16W

2400LM±10%

NON

ARK/DT/24YXXD306(15N)

2FT

24W

3600LM±10%

NON

ARK/DT/32YXXD406(15N)

2FT

32W

3600LM±10%

NON


Model

Size

Power

Luminous

Dimmable

CRICRI

ARK/DT/18YXXD112(15D)

4FT

18W

2700LM±10%

0-10v Dimming

80+3000K
4000K
5000K
6000K

ARK/DT/36YXXD212(15D)

4FT

36W

5400LM±10%

0-10v Dimming

ARK/DT/54YXXD312(15D)

4FT

54W

8100LM±10%

0-10v Dimming

ARK/DT/72YXXD412(15D)

4FT

72W

10800LM±10%

0-10v Dimming

ARK/DT/18YXXD112(15N)

4FT

18W

2700LM±10%

NON

ARK/DT/36YXXD212(15N)

4FT

36W

5400LM±10%

NON

ARK/DT/54YXXD312(15N)

4FT

54W

8100LM±10%

NON

ARK/DT/72YXXD412(15N)

4FT

72W

10800LM±10%

NON

Magnetic LED strip lights retrofit kits (T5 size)
Magnetic LED strip lights retrofit kits (T5 size)

Installation instructions:

LED Magnetic strip retrofit kits (T5 size)

-->

Magnetic LED strip lights retrofit kits (T5 size)

Installing Magnetic led troffer strip lights retrofit kits
